Those reductions make clear that federal headlight regulations, which have not changed significantly since 1968, are not stringent enough, IIHS stated. The federal standard specifies minimum and maximum brightness levels for headlights at various angles. However, it focuses on the headlight itself, without considering how well it is aimed once it is installed on a particular vehicle or how newer technologies such as curve-adaptive headlights may change that orientation when the vehicle is moving.
In contrast, IIHS uses vehicles driven on a test track to conduct its evaluations. The ratings are based on how far the low and high beams illuminate the path to 5 lux on curves and straightaways while traveling at 40-50 mph. Points are also deducted for glare that can temporarily blind oncoming drivers. (For reference, the end of twilight on a clear day is about 3 lux and the ambient light in the hallway of a typical office building is about 80).
Performance varies greatly. The low-beam illumination of headlights evaluated by IIHS ranges from 125’ to 460’. For the driver of a vehicle going 50 mph, that means a difference of 2 seconds versus 6 seconds to recognize a potential hazard and respond by braking or steering.
By exposing those gaps and making high-quality headlights a requirement for the TOP SAFETY PICK and TOP SAFETY PICK+ awards, IIHS has given manufacturers an incentive to make better headlights available on more vehicles.
Since the program began, the proportion of headlights earning a good rating has increased from 4% to 29%. Irrespective of their ratings, the average low-beam illumination distance for all the headlights tested rose from less than 180’ to more than 200’.
Though Brumbelow did not consider excessive glare in his analysis, measuring glare to oncoming drivers is also an important part of IIHS evaluations. Here, too, the ratings have driven improvements. In 2016, the headlight systems rated by IIHS emitted 15% more glare on average than the level IIHS determined to be acceptable. In 2020, average glare was 10% below that threshold.
The difference is sometimes stark. The headlights on one recently evaluated vehicle, the 2022 Mitsubishi Outlander, went from poor to good due solely to aim adjustments the manufacturer made to reduce glare in its bid for a TOP SAFETY PICK+ award, IIHS manager of active safety testing David Aylor pointed out.
“Based on some of the comments we get on social media, it seems like some people think we’re just pushing brighter headlights and ignoring glare,” Aylor said. “The reality is quite the opposite.”
Quality headlights have also become easier for customers to find as the Institute’s award criteria have evolved.
When the headlight ratings program began, the scores did not affect the TOP SAFETY PICK and TOP SAFETY PICK+ awards. In 2017, the Institute began requiring that at least one good or acceptable headlight system be available for a vehicle to qualify for TOP SAFETY PICK+. In 2019, that standard was adopted for the lower-tier award and at least one good-rated option was required for the “plus.” But in most cases the best headlights remained expensive add-ons that weren’t stocked by many dealers, so IIHS raised the bar again in 2020, requiring good or acceptable headlights across all trim levels for TOP SAFETY PICK+ and the availability of at least one good or acceptable headlight system for TOP SAFETY PICK.
That recent move has accelerated the disappearance of substandard headlights from the market and prompted manufacturers to simplify their offerings. Between 2019 and 2021, manufacturers reduced the number of headlight systems available for each vehicle model by 17%. Now many automakers are equipping models with a single, good-rated headlight system as standard equipment. Examples include the 2021 Acura RDX, BMW 5 series, Hyundai Palisade, and Subaru Outback.
Automakers have made midyear design changes to nearly 200 headlight systems in the quest for one of the two awards. Genesis went as far as to undertake a service campaign to make free, retroactive adjustments for buyers of the 2021 Genesis G80 to make sure it qualified for the highest accolade.
“Our awards have been a huge motivator for automakers to improve their headlights,” Brumbelow said. “Now, with our new study, we have confirmation that these improvements are saving lives.”
